Material Data Sheet (MDS): Polylac PA-757 (ABS)

1. Material Name

Polylac PA-757
Type: Acrylonitrile Butadiene Styrene (ABS), General Purpose

2. Description

Polylac PA-757 is a general-purpose ABS resin with excellent impact resistance, surface finish, and moldability. It is commonly used in automotive interiors, electronics housings, and consumer products.

3. Key Properties

Property	Value
Appearance	Opaque, customizable color
Density	~1.04 g/cm³
Tensile Strength	~45 MPa
Impact Resistance (Izod)	~200 J/m
Heat Deflection Temp	~80°C (176°F)
Flammability Rating	HB (UL 94)
Chemical Resistance	Moderate (avoid strong solvents)

4. Applications

• Automotive interior parts
• Consumer electronics housings
• Toys and appliances
• General-purpose enclosures

5. Processing Information

Parameter	Range
Mold Temperature	50–70°C
Melt Temperature	200–250°C
Drying Conditions	80°C for 2–4 hrs

6. Storage Conditions

• Store in a cool, dry area below 50°C.
• Avoid direct sunlight and moisture.

7. Cleaning & Maintenance Instructions

• Use 70% Isopropyl Alcohol (IPA) with a soft cloth for cleaning.
• Avoid aggressive solvents like acetone, toluene, or chlorinated agents.
• Do not expose to temperatures above 80°C (176°F).

Material Data Sheet (MDS): Cast Acrylic (PMMA)

1. Material Name

Cast Acrylic (PMMA – Polymethyl Methacrylate)
Type: Thermoplastic Polymer

2. Description

Cast acrylic is a rigid, optically clear thermoplastic offering excellent UV stability, surface hardness, and weather resistance. It is widely used as a glass substitute and in high-clarity applications.

3. Key Properties

Property	Value
Appearance	Transparent or tinted
Density	~1.19 g/cm³
Tensile Strength	~70 MPa
Impact Resistance	Moderate (~15 kJ/m²)
Heat Deflection Temp	~95°C (203°F)
UV Resistance	Excellent
Flammability Rating	HB (UL 94)
Chemical Resistance	Good; avoid strong solvents

4. Applications

• Glazing and windows
• Displays and signage
• Light diffusers and lenses
• Aquariums and museum cases

5. Processing Information

Parameter	Range
Forming Temperature	140–160°C
Machinability	Excellent (can be laser cut, CNC’d, or polished)

6. Storage Conditions

• Store flat in a dry, clean environment.
• Avoid exposure to direct UV light or extreme heat before use.

7. Cleaning & Maintenance Instructions

• Use a soft, non-abrasive cloth with 70% Isopropyl Alcohol (IPA) for cleaning.
• Do not use ammonia-based cleaners or solvents like acetone or toluene.
• Wipe gently and rinse with clean water if needed.
